Toyota Genuine Iridium Spark Plug 90919-01281 – DENSO FC16HR-C9

Toyota Genuine Iridium Spark Plug 90919-01281 – DENSO FC16HR-C9

Original Toyota spark plug manufactured to Toyota OE specification by DENSO for selected 2ZR-FXE 1.8L hybrid applications.

• Toyota part number: 90919-01281
• DENSO type: FC16HR-C9
• Plug type: Iridium long-life / OE high-performance spark plug
• Thread: M12 × 1.25
• Thread reach: 26.5 mm
• Required quantity: 4 plugs per 4-cylinder engine
• Brand: Toyota Genuine / DENSO
• Country of manufacture: Japan

Strict VPF mapping: mapped only to the exact year/engine paths in our locked Toyota master that can be represented safely without a mid-year production split: Prius 1.8L Hybrid 2016–2018 and C-HR 1.8L Hybrid 2017.

Production-date note: DENSO’s Japanese catalogue shows FC16HR-C9 / 90919-01281 on C-HR Hybrid ZYX10 from 12/2016 to 05/2018, after which Toyota changed to FC16HR-CY9 / 90919-01298. Therefore C-HR 2018 is not placed in the automatic VPF because the year contains both specifications. Early-2018 vehicles may still use this plug; confirm the existing plug or chassis/production date before ordering.

DENSO also lists 90919-01281 for early Prius PHV / Prime ZVW52 production in 2017, but that model-year is also split by production date, so it is intentionally excluded from the automatic VPF. Later applications generally use the superseding Toyota number 90919-01298 (FC16HR-CY9).
